150W 12V/12,5A Isolated DC/DC Converter, 43-160Vin, n=92%, Viso=3000VDC, UL


	Index Ropla	CIN0523
	Manufacturer's part number	CQB150W-110S12
	Manufacturer	Cincon
	Data sheet	cqb150w-110s.pdf (315,61KB)

CQB150W-110S SERIES 150 WATT 4:1 INPUT DC-DC CONVERTERS SINGLE OUTPUT

FEATURES:

• 150W Isolated Output
• Efficiency up to 92%
• Fixed Switching Frequency
• 4:1 Input Range
• Regulated Outputs
• Remote On/Off
• Low No Load Power Consumption
• Over Temperature Protection
• Over Voltage/Current Protection
• Continuous Short Circuit Protection
• Quarter Brick Size Meet Industrial Standard
• UL60950-1 2nd (Basic Insulation) Approval (Except 3.3 &15Vout)
• CB Test Certificate IEC60950-1 (Except 3.3 &15Vout)
• Meets EN50155 with External Circuits
• Shock & Vibration Meets EN50155 (EN61373)
• Fire & Smoke Meets EN45545-2
• 3000m Operating Altitude

RoHS	cincon_rohs.pdf (333,97KB) product compliant with the RoHS Directive
REACH	cincon_reach.pdf (400,51KB)
UL	ul_cqb150w-110s.pdf (14,81KB)
CE	ce_cqb150w-110s.pdf (625,46KB)

Product group	DC/DC Converters
Manufacturer	Cincon
Number of Outputs	1
Power	150W
Series	CQB150W-110S
Output Voltage 1	12V
Output Current 1	12.5A
Input Voltage	43V ~ 160V
Isolation Voltage	3000VDC
Efficiency	92%
Ripple/Noise	150mV p-p
Type	Isolated
Package/Case	QB
Mounting Style	THT
Remote On/Off Logic	positive
Industry	Railway System
Tₘᵢₙ	-40°C
Tₘₐₓ	100°C
Packaging	Antistatic Foam

Collective package	-/15/60 pcs
Weight	68.000000 g
Weight of the collective package	-/1,020 g/4,080 g
Customs number	85423990

1	pcs	Minimum order quantity
1	pcs	Multiple
-/15/60	pcs	Collective package
