100W 24V/4.2A Isolated DC/DC Converter, 18-75Vin, n=91%, Viso=1500VDC


	Index Ropla	CIN0613
	Manufacturer's part number	CHE100W-48S24
	Manufacturer	Cincon
	Data sheet	che100w.pdf (579,95KB)

CHE100/CHE100W SERIES 100 WATT 2:1/4:1 INPUT DC-DC CONVERTERS SINGLE OUTPUT

FEATURES:

• 100W Isolated Output
• Half-Brick Size, Six-Sided Shield Metal Case
• High Efficiency to 93%
• 2:1/4:1 Input Range
• Regulated Outputs
• 250KHz Switching Frequency
• Continuous Short Circuit Protection
• Input Under Voltage Protection
• Over Temperature/Voltage/Current Protection
• Remote On/Off
• Full Load Operation up to 60°C with Heat-sink M-C091 Natural Convention
• No Tantalum Capacitor Inside
• CE Mark Meets 2004/108/EC
• Safety Meets UL60950-1, EN60950-1 and IEC60950-1

RoHS	cincon_rohs.pdf (333,97KB) product compliant with the RoHS Directive
REACH	cincon_reach.pdf (400,51KB)
CE	ce_che100w.pdf (60,67KB)

Product group	DC/DC Converters
Manufacturer	Cincon
Number of Outputs	1
Power	100W
Series	CHE100W
Output Voltage 1	24V
Output Current 1	4.2A
Input Voltage	18V ~ 75V
Isolation Voltage	1500VDC
Efficiency	91%
Ripple/Noise	240mV p-p
Type	Isolated
Package/Case	HB
Mounting Style	THT
Remote On/Off Logic	positive
Tₘᵢₙ	-40°C
Tₘₐₓ	105°C
Packaging	Antistatic Foam

Collective package	-/12/24 pcs
Weight	95.000000 g
Weight of the collective package	-/1,140 g/2,280 g
Customs number	85423990

1	pcs	Minimum order quantity
1	pcs	Multiple
-/12/24	pcs	Collective package

0	pcs	on stock
NRND
