	Index Ropla	PDC4841
	Manufacturer's part number	CSMS0840D-3R6N-LRH
	Manufacturer	PDC
	Data sheet	csms0840d-xxxx-lrh.pdf (452,05KB)

Product group	Chokes
Manufacturer	PDC
Product Type	Inductor
Series	CSMS0840D
Technology	Wire Wound
Protection style	yes
Core Material	ferrite
Inductance	3.6µH
Tolerance	30%
Maximum DC Current I_RMS	4.90A
Maximum DC Resistance R_DC	15mΩ
Test Frequency f_L	100kHz
Saturation Current I_SAT	6.4A
Self Resonant Frequency SRF_min	34MHz
Product category	Shielded Power Inductor
Package/Case	8.0x8.0x4.2
Mounting Style	SMD
Packaging	Reel 13"
Tₘᵢₙ	-25°C
Tₘₐₓ	125°C

Collective package	1,000/2,000/8,000 pcs
Customs number	85041020

RoHS	pdc_rohs_coil.pdf (414,91KB) product compliant with the RoHS Directive
REACH	pdc_reach_coil.pdf (0,99MB)

1,000	pcs	Minimum order quantity
1,000	pcs	Multiple
1,000/2,000/8,000	pcs	Collective package
